Farm BOS Accessories Kit
Farm solar irrigation accessories including floating and ground PV mounts, water-level sensors, UV-resistant cables and connectors.
Product Overview
6.1 Floating Module (Floating PV Mount)
| Parameter | Specification |
| Material | HDPE Pontoon + AL6005-T5 Anodized Aluminum + SUS304 Stainless Steel |
| Wind Resistance | ≤ 60 m/s |
| Surface Wave Height | ≤ 0.5 m |
| Surface Flow Velocity | ≤ 0.5 m/s |
| Tilt Angle (Adjustable) | 5° / 10° / 15° |
| Warranty | 10 years |
6.2 Water Level Sensor
| Parameter | Specification |
| Protection Rating | IP68 (submersible probe) / IP67 (top module) |
| Measuring Range | 0–50 m H₂O (optional 0–200 m) |
| Output Signal | 4–20 mA / RS485 Modbus-RTU |
| Accuracy | ±0.25% – 0.5% FS |
| Power Supply | Solar PV + Lithium Battery, Battery Life ≥ 3 years |
6.3 Ground Solar Mount
| Parameter | Specification |
| Material | Hot-Dip Galvanized Steel / Anodized Aluminum |
| Minimum Ground Clearance | ≥ 2.5 m (agricultural access requirement) |
| Design Wind Speed | Calculated per local wind pressure; standard configuration covers ≥ 42 m/s |
6.4 Irrigation Cable & Connectors
| Category | Specification |
| PV DC Cable | UV-Resistant, 4 / 6 / 10 mm² |
| Connectors | MC4 / IP68 (pre-assembled MC4 connectors available) |
| Accessories Included | DC Circuit Breaker, Grounding Cable, Cable Ties, SPD (Surge Protection Device) |
One-Stop Procurement Advantage
Standardized, universally compatible BOS components — no compatibility concerns across brands
Single-source supply reduces procurement lead time and logistics cost
All accessories pre-tested for integration with Solhon solar pump and controller systems
Custom kit configurations available to match specific farm size and irrigation requirements
Complete technical documentation and installation guides provided with every kit
Applications
Large-scale agricultural solar irrigation projects
Floating solar PV systems on reservoirs and farm ponds
Agrivoltaic farms (solar panels above agricultural land)
Livestock farms and rural water supply infrastructure
Greenhouse and hydroponic solar-powered water systems
